PTW DIADOS E - 3 DIADOS E - Brief Operating Instructions

DIADOS E
T11035
Operating Manual – DIADOS E – Brief Operating Instructions
28
D616.131.00/10 en
3 DIADOS E – Brief Operating Instructions
Turn the device on
ON/OFF
Setup
RESET + APPL.
Selection of unit, timer, contrast and auto
power-off
data display
Connect detector
Socket
DETECTOR
DIADOS Diagnostic Detector T60004 for
dental and conventional radiography
DIADOS MAM Detector T60005 for mam-
mography
CT ion chamber TM30009, TM30017 or
TM77336 each with adapter
Select application
APPL.
RAD
DENT
CT
Mammography (MamM/M, MamM/R,
MamW/A, MamW/R, MamR/R, MamWAg)
Select filter/calibration factor
ALT + FILTER
Unatt.
Att.
Select operating mode
MODE
Normal mode with measurement of dose,
dose rate and time or
pulsed mode with measurement of dose,
dose per pulse and pulse
Select measuring range
ALT + RANGE
LOW, MEDIUM, HIGH or Auto Range
Display changeover
ALT
In normal mode toggle between dose, dose
rate and time or
in pulsed mode toggle between dose, dose
per pulse and pulse
Perform zero adjustment
ALT + ZERO
Measurement
AUTOSTART
or
START/STOP
Measurement begins when signal is de-
tected
Manual start and stop
Allow the device to warm up before zeroing and
before performing measurements.
DIADOS E is permanently in the Autostart mode.
This means that a measurement begins, as soon as
a signal is detected.
The START/STOP key can be used to initiate a
measurement manually.
Except for CT applications (dose length product
unit), the detector should always be fully irradiated.
While a measurement is in progress, the current
dose/dose rate is indicated in intervals of 0.5 s. The
ALT key can be pressed to toggle between the dif-
ferent readouts during a measurement.
