DIAMENTOR E2
Accessories and Spare Parts
D651.131.00/05 en 27
11 Accessories and Spare
Parts
Order No.
T11033 DIAMENTOR E2, DAP meter
T25024-2 Supply cable 24 VDC
T99052 Power supply according to
IEC 60601-1
T26060 Power limiter
T25030-3 RS232 interface cable
L104078 Wall mount for DIAMENTOR E2
on request DIAMENTOR chamber
This list of accessories and spare parts is valid at
the time of document
creation. The current list of
accessories and spare parts is available on request.
12 Special Adjustments
General information
CAUTION
The adjustments described below must only be
carried out by specially trained service techni-
cians.
Call up the Service menu by pressing the TEST and
PRINT buttons simultaneously. In the Service menu
mode the buttons are used for cursor control, to
change and confirm settings and to quit a menu.
Electrical calibration
When the Service menu is called up the current
setting for the electrical calibration factor CAL will
be shown. The factor is adjustable in the range
(0.01 ... 9.99).
Change the current digit with PRINT (↑) and move
to the next digit with TEST (→). Confirm the se-
lected setting with RESET (↵). After confirmation,
the menu for setting the test value will be entered
automatically. The electrical calibration factor will be
saved to the non-volatile memory.
Setting the test value
The menu for setting the test value will be entered
automatically when the setting for the electrical
calibration factor CAL in the Service menu (see
above) has been confirmed with RESET(↵).
The display shows dashes (---) and after a short
time the 4-digit test value. With RESET (↵) this
value will be confirmed and the measuring mode
will be entered automatically. The test value will be
saved to the non-volatile memory.
