PAGE 30 323 REV.030624
343 1 20172 RETAINING RING
400 1 ** PLANET HUB
410 3 20369 PLANET PIN
411 3 25004 CIRCLIP ROTOR CLIP C-87
413 3 25091 CIRCLIP ROTOR CLIP SH-87
420 3 ** PLANET GEAR
421 6 25068 THRUST WASHER #TRA 1423
423 60 25270 LOOSE ROLLER 5/32 X 1.25 TOR. #E151 - Q
430 1 ** **
431 1 25338 CIRCLIP ROTOR CLIP SH-300
440 1 ** SUNGEAR
444 1 20419 SUNGEAR STOPPER
450 1 ** PLANET HUB
456 1 ** SECONDARY HOUSING
460 3 20162 PLANET PIN
461 3 25122 CIRCLIP ROTOR CLIP C-100
463 3 25411 CIRCLIP ROTOR CLIP SH-100
470 3 ** PLANET GEAR
471 6 25098 THRUST WASHER TORRINGTON #TRA 1625
473 3 25097 NEEDLE BEARING TORRINGTON #BH 1620
481 1 21034 RETAINING RING
490 1 ** SUNGEAR
494 1 ** PLANET HUB STOPPER
531 1 25672 OIL SEAL
532 1 21033 BEARING STOPPER
533 1 25671 BEARING - SPHERICAL ROLLER SKF #23021 CC
534 1 21070 RETAINING RING
537 12 25081 CAPSCREW - HEX HEAD 1/2 - 13NC X 1.50 GRADE 5
539 1 25286 O-RING -277 11 1/2" ID 1/8" CS
541 12 25014 LOCKWASHER 1/2"
600 1 21032 CONNECTING SHAFT
601 1 25341 O-RING -239 3-5/8" ID 1/8" CS
603 1 25334 NEEDLE BEARING TORRINGTON #B2812
606 1 21086 BACKUP WASHER
607 1 25345 OIL SEAL
700 1 * BRAKE HOUSING
703 1 25347 PLASTIC CAPLUG 1 NPT THR' D
707 1 25339 O-RING -278 12" ID 1/8" CS
712 1 20451 BRAKE SPACER
713 6 25305 DIVIDER PLATE
715 5 25304 FRICTION PLATE
719 1 25336 CIRCLIP ROTOR CLIP SH-187
720 1 20446 BRAKE HUB
722 1 20455 SPRAG CLUTCH ALIGNER
723 1 25303 SPRAG CLUTCH
724 1 20421 SPRAG CLUTCH ALIGNER
727 1 25335 CIRCLIP ROTOR CLIP SH-196
744 1 25890 LOCKWASHER 7/8"
745 1 22613 CAPSCREW - HEX HEAD 7/8 - 9NC X 1.00 GRADE 5
750 1 20397 PISTON
751 1 25343 O-RING -90 DURO -451 11" ID 1/4" CS
752 14 20413 BRAKE SPRING
753 1 25342 O-RING -90 DURO -452 11-1/2" ID 1/4" CS
23191 WINCH SEAL KIT, CONSISTS OF ITEMS:
105, 213, 235, 531, 539, 601,606, 607, 707, 735, 751, 753 AND 801.
ITEM NO.
DESCRIPTION
PART NO.
QTY.
PARTS REFERENCE - BRAKE GROUP
Refer to PAGE 36 for ASSEMBLY DRAWING.
* This part varies according
to drum code.
Refer to APPENDIX B.
** This part varies according
to reduction code.
Refer to APPENDIX C.
