PAGE 32
323 REV.030624
DESCRIPTION
537 12 25081 CAPSCREW - HEX HEAD 1/2-13NC X 1.5 GRADE 5
541 12 25014 LOCKWASHER 1/2"
730 1 20415 MOTOR DRIVE SHAFT
731 1 25288 CIRCLIP ROTOR CLIP C-112
800 1 20401 MOTOR ADAPTOR
801 3 25127 O-RING -013 7/16" ID 1/16" CS
802 1 * *
805 2 25040 PIPE PLUG 1/8 - 27 NPT
806 1 * *
807 1 * *
809 1 * *
813 1 25031 PIPE PLUG 1/4 - 18 NPT
861 1 25350 GEAR HOUSING
865 4 25356 DOWEL PIN
869 2 25348 SEAL - GASKET
870 1 21761 PORT END COVER
875 4 25352 BEARING - ROLLER
877 2 25646 RING SEAL
881 1 25645 GEAR SET
885 2 25644 THRUST PLATE
887 4 25647 TEFLON SEAL
899 2 25031 PIPE PLUG 1/4 - 18 NPT
929 1 * *
950** 1 * SUB - ASSY MOTOR -086
951 8 25357 CAPSCREW - HEX HEAD 5/8 X 6.75 GRADE 5
953 8 25325 WASHER
955 2 25559 PLASTIC CAPLUG 2.0"
23117 MOTOR SEAL KIT, CONTAINS ITEMS:
869, 877 AND 887.
QTY.
ITEM NO. PART NO.
Refer to PAGE 30 for winch seal kit and PAGE 36 for ASSEMBLY DRAWING.
PARTS REFERENCE - MOTOR GROUP
* These part numbers and descriptions
vary according to brake code.
Refer to APPENDIX E.
** Item 950, MOTOR SUB-ASSY,
consists of items:
800, 802, 803, 804, 805, 807, 809,
861, 865, 869, 870, 875, 877, 881,
885, 887, 899, 929, 951, 953 AND 955.
