Pulnix TMC-7DSP - Physical Dimensions

APPENDIX
TMC-7DSP/TMC-6DSP Color CCD Camera Page 29
6.1.2 Physical Dimensions
FIGURE 14. Physical Dimensions
32 mm
42 mm
25 mm
1/4 - 20 UNC -2B
35 mm
25 mm29 mm
48 mm
M2.6 x 7mm. deep (4x)
1/4-20 UNC-2B
50mm
REMOTE HEAD
8
118 mm (Remote)
133mm
146mm
PULNiX
PULNiX
VIDEO
OPTION
AWB
SHUTTER
PWR/RGB
MODE
0
1
2
3
5
6
7
8
9
4
1
2
3
4
