APPENDIX
TMC-7DSP/TMC-6DSP Color CCD Camera Page 31
FIGURE 17. Combination With “CS-Mount” Camera
6.1.5 Front End Detail
FIGURE 18. Front End Detail
C-Mount Lens
Focal Point
5mm Extension Ring
5
12.5
17.526
Flange Surface of
C-Mount
