Pull cord recoils rapidly and pulls arm towards engine faster than you can let go which
could result in injury.
Never start or stop engine with electrical devices plugged in to the receptacles. Failure to
do so could damage the generator and / or connected electrical devices.
Receptacles and Extension Cords
This generator is equipped with the following receptacles:
Battery Charger for Electric Starter
How to Stop Engine (See fig 15-18))
MUST
2
2
• Four 120 Volt AC, 20 Amp receptacles.
• 2020Volt AC, 0 Amp receptacle (NEMA L-0).
• 120 / 240 Volt AC, 30 Amp twist lock receptacle (NEMA L14-30).
• 12 Volt 8.3 Amp Output (For charging batteries only)
120 Volt AC, 20 Amp receptacle
• This receptacle has a 20 Amp push-to reset circuit breaker to protect against overload.
• Each socket is rated to operate 120 Volt, AC, single phase, 60Hz loads requiring up to 2400 watts (2.4 kW) at 20 Amps.
• Use extension cords having a minimum rating of 125 Volts AC, 20 Amps.
