Pulsar PG1202S - Cylinder Head System Assy

PG1202S MANUAL
Cylinder Head System Assy
A
No.
Parts No.
Description
1
PG1202S-A-01
FLANGE BOLT (M6× 12)
2
PG1202S-A-02
CYLINDER AIR SHROUD
3
PG1202S-A-03
NUT (M6× 18)
4
PG1202S-A-04
STUD BOLT (M6× 110)
5
PG1202S-A-05
FLANGE BOLT (M6× 105)
6
PG1202S-A-06
SPARK PLUG
7
PG1202S-A-07
CYLINDER HEAD
8
PG1202S-A-08
CYLINDER HEAD GASKET
9
PG1202S-A-09
CYLINDER LINER
10
PG1202S-A-10
CYLINDER BOTTOM GASKET
