PureLink PT-E-HD50 - Technical Specifications

User Manual
PT-E-HD50
4.Specications
Technical TX RX
Role of usage Transmitter [TX] Receiver [RX]
HDMI compliance HDMI Deep Color, full 3D & 4K2K@30/40m
HDCP compliance Yes
Video bandwidth Single-link 340MHz [10.2Gbps]
Video support 480i / 480p / 720p / 1080i / 1080p60
HDMI over UTP 1080p@60 100m (330ft) [CAT5e]
Audio support
Surround sound [up to 7.1ch] or stereo digital audio
Equalization
Auto
Input TMDS signal 1.2 Volts [peak-to-peak]
Input DDC signal 5 Volts [peak-to-peak, TTL]
ESD protection
[1] Human body model — ±19kV [air-gap discharge] & ±12kV [contact discharge]
[2] Core chipset — ±8kV
PCB stack-up 6-layer board [impedance control — dierential 100Ω; single 50Ω]
IR pass-thru Bi-directional
RS-232 support Yes
POC support Yes
Input 1x HDMI/1x 3.5mm 1x RJ-45(Video)/1x 3.5mm
Output 1x RJ-45(Video)/1x 3.5mm 1x HDMI/1x 3.5mm
In / Out 1x RS-232/2x RJ-45(Ethernet) 1x RS-232/2x RJ-45(Ethernet)
HDMI source control Controllable via IR pass-through from RX to TX with IR extenders
HDMI connector Type A [19-pin female]
RJ45 connector WE/SS 8P8C(Reverse Mode)
Rotary switch None
3.5mm connector IR receiver / IR blaster IR receiver / IR blaster
Mechanical TX RX
Housing Metal enclosure
Dimensions
[L x D x H]
Model 100 x 89 x 27mm [3.9“ x 3.5“ x 1“] 100 x 89 x 27mm [3.9“ x 3.5“ x 1“]
Package 325 x 196 x 92mm[12.7" x 7.7" x 3.6"]
Carton 490 x 426 x 352mm[1'6" x 1'4" x 1'2"]
Weight
Model 320g [11 oz] 320g [11 oz]
Package 720g [1.6 lbs]
Fixedness Wall-mounting case with screws
Power supply 24V 1A
Power consumption Max 12W
Operation temperature 0~50°C
Storage temperature -20~60°C [-4~140°F]
Relative humidity 20~90% RH (no condensation)
