8
Step 4: Position the Direct jacketed
4-conductor main harness so it
will reach the 2-stud strip and
all the slack has been taken up.
Mark the jacketed 4-conductor
main harness so it can be taken
back out of the battery box to be
terminated.
Note: If your battery box includes a slide-out tray, include enough slack to
allow the tray to fully extend without tugging the wire connections.
Step 5: Pull the jacketed 4-conductor
main harness out of the box
(making it easier to work on), and
cut o the excess at the mark.
Step 6: Cut about 8 inches o the
jacketed portion of the 4 wires.
