Trigger condition
Description
Extro
Forward Follow
If DI is high level, DO outputs high level. If DI
is low level, DO outputs low level.
Only available for coil value.
Reverse Follow
If DI is high level, DO outputs low level. If DI
is low level, DO outputs high level.
Only available for coil value.
Greater than
The collected value exceeds the threshold,
an action is triggered.
Only the lower of the thresholds
need be set.
Equal or greater than
The collected value is greater than or equal
to the threshold, an action is triggered.
Only the lower of the thresholds
need be set.
Less than
The collected value is less than the
threshold, an action is triggered.
Only the upper of the thresholds
need be set.
Equal or less than
The collected value is less than or equal to
the threshold, an action is triggered.
Only the upper of the thresholds
need be set.
In the Range (Including
boundary data)
An action is triggered when the collected
value is within the threshold range, and an
action is triggered each time the collected
value is within the range.
Upper and lower limits of the
thresholds need be set.
In the Range (Excluding
boundary data)
An action is triggered when the collected
value is within the threshold range, and an
action is triggered each time the collected
value is within the range.
Upper and lower limits of the
thresholds need be set.
Out of the Range(including
boundary data)
An action is triggered when the collected
value is outside the threshold range, and an
action is triggered each time the collected
value is outside the range.
Upper and lower limits of the
thresholds need be set.
Out of the
Range(excluding
boundary data)
An action is triggered when the collected
value is outside the threshold range, and an
action is triggered each time the collected
value is outside the range.
Upper and lower limits of the
thresholds need be set.
