TOOL MASTER Lite 14
5
MANUAL © Evoset AG
3. Parts breakdown
A. Z-Axis Magnetic Band
B. Z-Axis Guide
C. Z-Axis Display/Control
D. Z-Axis Locking Knob
E. X-Axis Locking Knob/backside
F. X-Axis Magnetic Band
G. X-Axis Fine Adjustment Knob
H. X-Axis Guide
I. Probe
J. Spindle/ Needle bearing sleeve
K. Base
L. Support Legs
M. X-Axis Display/Control
C
E
B
D
G
M
H
F
I
K
J
L
