4 5
INSTALLATION
1. Remove the screws from bracket like below picture to install the bracket
on iron tube.
2. Put the plastic bracket parts in between two metal poles, at the same
time, push 2 screws to x up bracket.
3. Hold up unit, insert the metal plate at the back of the unit into plastic
bracket parts, then adjust it to the right angle and x it tightly, at last
lower the orignal car headrest to the appropriate position.
WIRING DIAGRAM
Mini Din Connector Attach power cable to connect
INSTALLATION COMPLETE
