ww w.PyleUSA.com
5
1-2. Main bus inputs allow outputs from receivers, CD players, TVs, or any stereo
audio sources to be amplied across all channels for easy multi-room
applications. Auxiliary inputs allows an addition audio source to be played on
any channel that is switched to AUX .
3-4. Bus outputs allows the bus inputs to be sent to other ampliers or a daisy chain
without the need for “Y” cable splitters. Auxiliary output allows you to daisy
chain the input to other audio sources.
5. Bridging switch allows you to easily double the power output by coupling
two channels together.
6. Level controls for each channel.
7. Input Selection switch allows you to select between the common bus and
auxiliary inputs or the individual channel input.
8. One switch allows you to select which stereo Input channel will play through
the speaker outputs: left, right, or left and right combined. lf switched to Left
+ Right, both input channels are combined.
9. Gold plated individual channel inputs allow you to connect dierent audio
sources to each channel.
10. Line signal output
11. Voltage Selector 110-220V
12. The Power Mode switch is used to toggle between three dierent trigger
methods to power up the amplier.
13. 12V output to turn on other devices when amplier is powered up.
Connect to projector screens, powered drapes, or other devices with voltage
triggers.
14. 12-15V A/C or D/C input to trigger power up with voltage from another
device, such as a receiver.
15. Speaker channel output binding posts.
16. Speaker channel bridged mode binding.
17. 3-Prong removable power plug.
18. Fused AC
