Pyronix PCX 78 User Manual

No. Output
Type
Active Restore
0004 Final Arm All When ALL areas are armed At code entry to disarm
0005 Open After
Alarm (Abort)
When system is silenced after ‘burglary’ alarm
has been activated
After 2 minutes
0007 Tamper Any Tamper alarm in any area At code entry to silence
0008 Duress Any At a Duress alarm in any area When a valid code is entered
0009 PA Device Any At alarm on a PA input only from any area. (This
does not include the keypad PA)
When a valid code is entered
0010 Gas At gas alarm When a valid code is entered
0011 Arm Fail Pre-set time after start of exit time, if exit
procedure is not complete
At code entry to rearm
0012 Entry
Deviation
When deviation from entry route occurs, during
entry time
At code entry to disarm
0013 System Ready
Any
When any of the inputs but the Entry Delay and
Follow are closed
If fault exists, and after final arm
0014 Bell Any After alarm in any area When alarm silenced or when siren timer expires
0016 Strobe Any After alarm in any area When disarmed or when strobe timer expires
0017 Bypass Rearm
Any
When inputs are bypassed at rearm in any area When system disarmed
0018 Burglary
(Unconfirmed)
Any
At Burglary alarm in any area At code entry to silence
0019 Ready All When all inputs but the ‘Entry Delay’ and ‘Follow’
inputs are closed
If fault exists, and after final arm
0020 Exit Starts All At start of exit time to arm LAST area At disarm FIRST area (i.e. no longer fully armed)
0021 Exit Starts
Any
When exit time starts to arm FIRST area At code entry to disarm LAST area
0022 Final Arm Any When ANY area has been armed At code entry to disarm LAST area
0023 Strobe if Arm
Fail
Works similar to output 016, but also fires if the ‘arm fail’ timer expires
0024 Unable to
Arm
This output turns on for 5 seconds when the system is disarmed via a keyswitch input (either pulsed
or latched keyswitch)*
0025 Keyswitch
Disarm
Output activates when an arming procedure is completed with inputs bypassed
0026 Arm with
Bypass
Active when the system is armed with an input bypassed
0027 Pulsed
Burglary Any
Active when burglary alarm is triggered, but deactivates once the Pulsed Intruder timer has expired
0028 Power Fault Active during low volts and battery faults. Restores at code entry after fault cleared
0031 Entry Active during any Entry time
0032 Exit Active during any Exit time
0033 Entry / Exit Active during any entry or exit time
0034 Lights When exit or entry timer starts 20 seconds after arm/disarm procedure
completed
PCX Installation Guide 102017852 - V01 83
