No. Output
Type
Active Restore
0035 Follow Input Active when a specific input number has been activated. It allows the following options to be
programmed:
- Follow Type (Follow, Timed, Latched, Code Reset);
- Follow What (Input, Sub-Area, Area);
- Follow When (Always, When Armed, When Disarmed);
- Input to Follow (between 1 to 64)
0037 Restore 1 At code entry to arm. The normal state of this
input is 0v and it changes to 12v when activated.
After 3 seconds
0038 Restore 2 Activates whenever an additional area is armed.
The normal state of this input is 0v and it
changes to 12v when activated.
When disarmed
0039 PIR Latch 1 When armed (and in Walk Test) At alarm, or when disarmed
0040 PIR Latch 2 This is the inverse polarity to PIR Latch 1 At alarm, or when disarmed
0041 AC Mains
Good
Output showing the 230v mains supply is present
0042 PIR LED
Enable
This output activates during walk test
0043 Follow Test Output will activate only when tested from the Engineer Menu Test Outputs’ in the ‘Engineer Tests’.
This output can be used as additional facility for testing the operation of a Bell. An output
programmed to one of these configurations (43 and 44) may be used to trigger a relay to break the
hold-off connection to the Bell or even to provide the hold-off directly.
0044 Off During
Test
Output is normally active and will deactivate only when tested from the Engineer Menu ‘Test Outputs’
in the ‘Engineer Tests’.
Same as 43 but opposite activation.
0048 Walk Test This output is active during walk test, and will only deactivate when all detectors have been tested
0049 Detector
Masked
If any detector goes into ‘mask’ condition the
output will activate
When masking fault clears
0050 Follow 24
Hour
If any input programmed as 24 Hour’ activates When input is restored
0051 Line/GPRS
Fault
When Telephone or GPRS Line Fault is present When fault clears
0052 AC Mains Fail After pre-set time without mains power On restoration of mains
0053 Battery Fault When battery disconnected or load fail detected At next valid code entry
0054 Low Volts When less than 11.2v are present When fault clears
0055 Global Fault 1
(Grade 2)
Activates if any fault occurs only when system is
armed
When all faults cleared
0056 Global Fault 2
(Grade 3)
Activates if any fault occurs at any time When all faults cleared
0057 German Relay For future development. Do Not Use.
0058 Guard Code
Used
When ‘guard code used on the system After 60 seconds
0059 Engineer
Access
When entering Engineer Mode When leaving Engineer Mode
0060 Follow Power
Up
At power up Live for 45 seconds
0063 Test UK STU Activates when a test call is sent When test completed
84 PCX Installation Guide 102017852 - V01
