Python Responder LC Model 991 User Manual

11
© 2008 Directed Electronics. All rights reserved.
Primary harness (H1), 12-pin connector
H1/1
RED/WHITE (-) 200mA TRUNK RELEASE OUTPUT
H1/2
RED (+)12v CONSTANT INPUT
H1/3
BROWN (+) SIREN OUTPUT
H1/4
WHITE/BROWN LIGHT FLASH ISOLATION WIRE - PIN 87a of onboard relay
H1/5
BLACK (-) CHASSIS GROUND
H1/6
VIOLET (+) DOOR TRIGGER INPUT
H1/7
BLUE (-) TRUNK PIN/ INSTANT TRIGGER INPUT
H1/8
GREEN (-) DOOR TRIGGER INPUT
H1/9
BLACK/WHITE (-) 200mA DOME LIGHT OUTPUT
H1/10
WHITE/BLUE (-) REMOTE START/ TURBO TIMER ACTIVATION INPUT
H1/11
WHITE PARKING LIGHT OUTPUT
H1/12
ORANGE (-) 500mA GROUND WHEN ARMED OUTPUT
Auxiliary harness (H2), 8-pin connector
H2/1
LIGHT GREEN/
BLACK
(-) 200mA FACTORY ALARM DISARM OUTPUT
H2/2
LIGHT GREEN/
WHITE
(-) 200mA FACTORY ALARM ARM OUTPUT
H2/3
WHITE/VIOLET (-) 200mA AUX 1 OUTPUT
H2/4
VIOLET/BLACK (-) 200mA AUX 2 OUTPUT
H2/5
WHITE/BLACK (-) 200mA AUX 3 OUTPUT
H2/6
LIGHT BLUE (-) 200mA 2ND UNLOCK OUTPUT
H2/7
GRAY/BLACK (-) DIESEL WAIT TO START INPUT
H2/8
BROWN/BLACK (-) 200Ma HORN HONK OUTPUT
There are three harness connections relative to remote start function, including
the heavy gauge and input and output harnesses.
