34
© 2008 Directed Electronics. All rights reserved.
Remote control learn routine™
The system comes with a 1-way and a 2-way remote control that are already
programmed to the system. The system can store up to 4 different remote control
codes in memory.
The remote uses a Supercode Protocol and requires setup before programming
the system.
Remote Control Programming
2 way programming
Make sure the keypad is unlocked.1.
Press and hold the 2. button on the remote for approximately 8 seconds ,
at 3 seconds ignore the car select indicator and continue to hold. The LC
text displays Main Menu until the button is released.
Release the 3. button. The LC text displays the remote setup options ta-
ble.
Pressing the 4.
AUX
button steps up one Main Menu option per press and
pressing the button steps down one Main Menu option per press.
When the Pair Remote menu option is displayed, press and hold the but-5.
ton for 1 second. The remote emits 3 short beeps and the LC text displays
Pair.
Now enter the remote control learn routine using the control center (as 6.
described on the following page) and choose the Auto learn standard
configuration function listed on the program grid.
1 way programming:
Hold the button on the remote until you hear it emit a long beep.
The transmit LED comes on solid (approximately 8 seconds). 1.
Press and hold the 2. button and the amber Transmit LED lights up.
Next enter the remote control learn routine and choose the function for 3.
“auto learn configuration” listed on the program grid.
Note:
You do not need to go through the setup for the other features in the
menu.
