56
© 2008 Directed Electronics. All rights reserved.
Table of zones
When using the Diagnostic functions, use the Table of Zones to see which input
has triggered the system. It is also helpful in deciding which input to use when
connecting optional sensors and switches.
ZONE NO. TRIGGER TYPE INPUT DESCRIPTION
1 Trunk Input BLUE (H1/7)
2 Shock Sensor Onboard shock sensor
3 Door Trigger GREEN (H1/8) and VIOLET (H1/6).
4 Sensor 2 Optional MUX sensor port
5 Ignition Heavy gauge pink of remote start harness
6 Hood Trigger GRAY on the 6-pin shutdown harness.
Note:
The WarnAway® response does not report on the LED
Shutdown diagnostics
To perform shutdown diagnostics:
With the ignition OFF, press and hold the Valet/Program switch.1.
Turn the ignition ON and then back OFF while holding the Valet/Pro-2.
gram switch.
Release the Valet/Program switch.3.
Press and release the Valet/Program switch. The LED flashes to report 4.
the last shutdown for one minute or until the ignition is turned on, as
shown in the following table:
LED Flashes Shutdown Mode
1 flash Runtime expired
2 flashes Over-rev shutdown
3 flashes Low or no RPM
4 flashes Transmitter shutdown (or optional push button)
5 flashes (+) Brake shutdown
6 flashes (-) Hood shutdown
