QDI Superb 4 Series User Manual

Manual for S4 series
Chapter 3
QDI Innovation features
Figure-3 QDI Innovation features Menu
The following indicates the options for each item and describes their meaning.
Item Option Description
[SpeedEasyII setting]
lCPU Clock Ratio x8~50 Select the multiplication of processor core
frequency. If a Ratio -locked processor
installed, this item will be hidden. This item is
only for users who understand all the CPU
parameters. This function will not take effect
for bus ratio locked processor.
Key in a Fill in a DEC number of the ratio you want .
DEC number
lCPU Frequency 100 Set CPU frequency as100MHz.
133 Set CPU frequency as 133MHz.
lDRAM Frequency By SPD Set DRAM frequency by SPD.
200MHz set DRAM frequency manually.
266MHz .
333MHZ
lCPU Voltage Default Set CPU frequency.
- 0.075V
... ...
+ 0.300V
