LED Status Description
Power supply Green The power supply unit is on
Flashing green (1 Hz) The power supply unit has +5VSB
standby supply power
Orange • The power supply unit is
failing
• OCP is activated
• OTP is activated
• OVP is activated
• UVP is activated
• The fans are failing
Flashing orange (1 Hz) • The temperature is too high
• The power is too strong
• The current is too high
• The fan is too slow
• The voltage is too low
Off The power supply unit is off
Node
This section provides information on components on the node. These components apply to both nodes.
Rear Panel
GM-1000 User Guide
Product Overview 14
