• Only qualified personnel should perform the following steps. Failure to follow
instructions can result in serious injury or death.
• Observe electrostatic discharge (ESD) procedures to avoid damage to components.
•
Moving fan blades: Keep your hands and other body parts away from moving fan
blades.
•
Other moving components: Keep your hands and other body parts away from other
moving components.
1. Remove the node.
For details, see Removing a Node.
2. Optional: Remove an existing module.
a. Push the retention clips outward simultaneously to release the module.
Warning
Attempting to remove a module that is not completely released may damage the module and
the motherboard.
b. Hold the module by the edges.
c. Carefully slide the module out of the slot.
3. Install a new module.
a. Align the notch with the ridge in the slot.
GM-1000 User Guide
Installation and Configuration 36
