Component TL-R1200PES-RP TL-R1600PES-RP TL-R2400PES-RP
Dimensions (H x W x
D)
88.65 x 482.2 x 423.8 mm
(3.49 x 18.98 x 16.68 in)
131.3 x 482.2 x 425.3 mm
(5.17 x 18.98 x 16.74 in)
176.15 x 480.74 x 672.05
mm
(6.94 x 18.93 x 26.46 in)
Net weight 9.22 kg (20.33 lbs) 11.56 kg (25.49 lbs) 18.67 kg (41.16 lbs)
Others
Hot-plugging This device supports hot-plugging on a QNAP NAS.
For details, see Hot-plugging the JBOD enclosure on a NAS.
Rail compatibility Rail-B02 Rail-B02 Rail-A02-90
Note
• Rail kits are not included with the NAS and must be
purchased separately. For details, contact an authorized
reseller or go to https://shop.qnap.com.
• Information on rail kit installation can be found in the
installation guide included in the rail kit package. For details,
go to https://www.qnap.com/go/product/rail-kit.
Power supply unit 2 x 300W, 100-240V AC,
50/60 Hz
2 x 550W, 100-240V AC,
50/60 Hz
2 x 550W, 100-240V AC,
50/60 Hz
Fans 2 x 80 mm, 12V DC fan 3 x 80 mm, 12V DC fan 3 x 80 mm, 12V DC fan
Operating
temperature
• Non-condensing relative humidity: 5% to 95%
• Wet-bulb temperature: 27˚C (80.6˚F)
Tip
For the list of compatible drive models, go to https://www.qnap.com/compatibility.
Package contents
Item Quantity
JBOD enclosure 1
Power cord 2
PCIe JBOD special cable (SFF-8644 1x2) 1 x CAB-PCIE10M-8644-8X
Screws for 3.5-inch drives • TL-R1200PES-RP: 48
• TL-R1600PES-RP: 64
• TL-R2400PES-RP: 96
Screws for 2.5-inch drives • TL-R1200PES-RP: 36
• TL-R1600PES-RP: 48
• TL-R2400PES-RP: 72
Quick Installation Guide (QIG) 1
Components
QNAP JBOD Enclosure User Guide | TL-R1200PES-RP, TL-R1600PES-RP, TL-R2400PES-RP
Product Overview 6
