QNAP TS-131 User Manual

39
Chapter 2. Power Button and Reset Button Behavior
 Power button: Press to turn on or turn off.
System
Power button
(Turn on)
Power button
(Hardware turn
off)
Power button
(Force turn off)
All models Press once 1.5 sec 5 sec
 Reset button: Press to reset the system settings.
System
Basic system reset
(1 beep)
Advanced system reset
(2 beeps)
All models 3 sec 10 sec
Basic system reset (3 sec)
Press the reset button for 3 seconds, a beep sound will be heard. The following settings are
reset to default:
 System administration password: admin
 TCP/IP configuration: Obtain IP address settings automatically via DHCP
 TCP/IP configuration: Disable Jumbo Frame
 TCP/IP configuration: If port trunking is enabled (dual LAN models only), the port
trunking mode will be reset to “Active Backup (Failover)”.
 System Port: 8080 (system service port)
 Security Level: Low (Allow all connections)
 LCD panel password: (blank)*
 VLAN will be disabled
*This feature is only provided by the NAS models with LCD panels. Please
visit
http://www.qnap.comfor details.
Advanced system reset (10 sec)
Press the reset button for 10 seconds; you will hear two beeps at the third and the tenth
seconds. The NAS will reset all the system settings to default as it does by web-based
system reset in “Administration” > “Restore to Factory Default” except all the data are
reserved. The settings such as the users, user groups, and the network share folders
previously created will be cleared. To retrieve the old data after the advanced system reset,
create the same network share folders on the NAS and the data will be accessible again.

QNAP TS-131 Specifications

General

Storage drive size	2.5/3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	- GB
Storage drive interface	Serial ATA II, Serial ATA III
Storage drives installed	No
Supported storage drive types	HDD & SSD
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	1
Processor cores	2
Processor model	Cortex-A9
Processor family	Freescale
Processor frequency	1.2 GHz
Processor architecture	ARM Cortex-A9
Flash memory	512 MB
Internal memory	0.512 GB
Internal memory type	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Chassis type	Tower
Cooling type	Active
Fan diameter	50 mm
Product color	White
LED indicators	HDD, LAN, Status, USB
Number of fans	1 fan(s)
Cable lock slot type	Kensington
Type	NAS
Noise level	14 dB
Device class	Home & Home Office
Share folder	CIFS/SMB
Backup features	Cloud, iSCSI LUN
Browser supported	Microsoft Internet Explorer 10+, Mozilla Firefox 8+, Apple Safari 4+, Google Chrome
Security algorithms	256-bit AES, HTTPS, SSH, SSL/TLS
Operating system version	4.1
Operating system installed	QNAP Turbo System
Server operating systems supported	Windows Server 2003
Windows operating systems supported	Windows 7 Enterprise
Fan voltage	12 V
AC input voltage	100-240 V
Power supply location	External
Power consumption (sleep)	6.26 W
Power consumption (typical)	13.31 W
Power supply unit (PSU) capacity	36 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	FCC, CE, BSMI, VCCI, C-TICK
Cables included	AC, LAN (RJ-45)

Weight and Dimensions

Depth	219 mm
Width	73 mm
Height	169 mm
Weight	1040 g
Package weight	1800 g
