QNAP TS-131 User Manual

41
Chapter 4. LED and Alarm Buzzer Specifications
The LED indicators of the NAS indicate the system status and information. When the NAS is
turned on, check the following items to make sure the system status is normal. Note that
the following LED information is applicable only when users have properly installed the hard
drive, and connected the NAS to the network and the power supply.
LED Color LED Status Description
System
Status
Red/
Green
Flashes green
and red
alternately
every 0.5 sec
1. The hard drive on the NAS is being
formatted.
2. The NAS is being initialized.
3. The system firmware is being updated.
4. RAID rebuilding is in process.
5. Online RAID Capacity Expansion is in
process.
6. Online RAID Level Migration is in process.
Red
1. The hard drive is invalid.
2. The disk volume has reached its full
capacity.
3. The disk volume is going to be full.
4. The system fan is out of function.
5. An error occurs when accessing
(read/write) the disk data.
6. A bad sector is detected on the hard
drive.
7. The NAS is in degraded read-only mode
(2 member drives fail in a RAID 5 or RAID
6 configuration, the disk data can still be
read).
8. Hardware self-test error.
Flashes red
every 0.5 sec
The NAS is in degraded mode (one member
drive fails in RAID 1, RAID 5 or RAID 6
configuration).
Flashes green
every 0.5 sec
1. The NAS is starting up.
2. The NAS is not configured.
3. A hard disk drive is not formatted.
Flashes green
every 2
seconds
The NAS is in S3 sleep mode
1
.
Green The NAS is ready.
Off
All the hard disk drives on the NAS are in
standby mode.
1
This feature is only available on certain NAS models. Please refer to the product specification table
for details at www.qnap.com.

QNAP TS-131 Specifications

General

Storage drive size	2.5/3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	- GB
Storage drive interface	Serial ATA II, Serial ATA III
Storage drives installed	No
Supported storage drive types	HDD & SSD
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	1
Processor cores	2
Processor model	Cortex-A9
Processor family	Freescale
Processor frequency	1.2 GHz
Processor architecture	ARM Cortex-A9
Flash memory	512 MB
Internal memory	0.512 GB
Internal memory type	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Chassis type	Tower
Cooling type	Active
Fan diameter	50 mm
Product color	White
LED indicators	HDD, LAN, Status, USB
Number of fans	1 fan(s)
Cable lock slot type	Kensington
Type	NAS
Noise level	14 dB
Device class	Home & Home Office
Share folder	CIFS/SMB
Backup features	Cloud, iSCSI LUN
Browser supported	Microsoft Internet Explorer 10+, Mozilla Firefox 8+, Apple Safari 4+, Google Chrome
Security algorithms	256-bit AES, HTTPS, SSH, SSL/TLS
Operating system version	4.1
Operating system installed	QNAP Turbo System
Server operating systems supported	Windows Server 2003
Windows operating systems supported	Windows 7 Enterprise
Fan voltage	12 V
AC input voltage	100-240 V
Power supply location	External
Power consumption (sleep)	6.26 W
Power consumption (typical)	13.31 W
Power supply unit (PSU) capacity	36 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	FCC, CE, BSMI, VCCI, C-TICK
Cables included	AC, LAN (RJ-45)

Weight and Dimensions

Depth	219 mm
Width	73 mm
Height	169 mm
Weight	1040 g
Package weight	1800 g
