QNAP TS-1677X Series User Manual

3. Install a drive on the tray.
a. Align the SATA connector on the drive with the opening at the end of the tray.
b. Place the drive on the tray.
4. Load the tray into the bay.
a. Insert the tray into the bay.
b. Push the handle.
c. Slide the lock up.
TS-1677X User Guide
Installation and Configuration 19
