11
1.3 Components
Front View
No. Component
1 LCD panel
2 Enter button
3 Select button
4 IR sensor
5 Power LED (adjustable brightness)
6 Power button
7 Status LED
8 USB One-touch Copy button
9 USB 3.0 One-touch Copy port
10 M.2 SSD LEDs
11 SSD LEDs
12 HDD LEDs
