QNAP TS-231 User Manual

101
System Support
s
3.5-inch
SATA
Hard
Drives
Support
s
2.5-inch
SATA
Hard
Drives
Suppor
ts 2.5”
SATA
SSD
Supports
M.2 SATA
SSD
Supports
Hot-swappa
ble Hard
Drives
(RAID 1 or
above only)
Pro, TS-853S Pro,
IS-453S, TVS-882S,
TVS-882ST
TVS-473, TVS-673,
TVS-873
✔ ✔ ✔
✔ (2280,
2260)
✔
TBS-453A
✔ (2280,
2260, 2242)
The NAS supports hot-swapping the hard drives when 1 member drive crashes in RAID 1,
1–2 member drives crash in RAID 5 or RAID 6. Follow the steps below to hot-swap the hard
drive when a member drive fails in a RAID configuration.
1. Login the NAS and check the disk volume configuration in “Volume Management”.
2. The volume status should be “in degraded mode”.
3. Prepare a new hard drive to replace the failed one. The capacity of the new hard drive
should be the same as or larger than the failed hard drive.
4. Unplug the failed drive from the NAS. Wait for about 20 seconds or until the server
beeps twice.
5. Remove the failed drive from the drive tray.
6. Install the new hard drive on the drive tray. Insert it to the NAS.
7. The server should beep 1.5 seconds twice.
8. Check the volume status on the web administration page. The volume should be
rebuilding.
Warning: Users are strongly recommended to turn OFF the server before replacing

QNAP TS-231 Specifications

General

Flash Memory	512MB
Drive Bays	2
LED Indicators	Status, LAN, USB, HDD1, HDD2
Form Factor	Tower
Power Supply	External Power Adapter, 60W, 100-240V
CPU	Annapurna Labs Alpine AL-212 1.7 GHz dual-core
RAM	512MB DDR3
Maximum Internal Raw Capacity	16TB (2 x 8TB HDD)
Network Interface	1 x Gigabit RJ45 Ethernet port
Buttons	Power, Reset
Weight	1.28 kg
Fan	1 x 70 mm, 12V DC
Operating System	QTS (Embedded Linux)
Power Consumption (In Operation)	15.6W
USB Ports	2 x USB 3.0
