29
Chapter 2. Power Button and Reset Button Behavior
Power button: Press to turn on or turn off.
System
Power button
(Turn on)
Power button
(Hardware turn
off)
Power button
(Force turn off)
All models
Press once
1.5 sec
5 sec
Reset button: Press to reset the system settings.
System
Basic system reset
(1 beep)
Advanced system reset
(2 beeps)
All models
3 sec
10 sec
Basic system reset (3 sec)
Press the reset button for 3 seconds, a beep sound will be heard. The following settings are
reset to default:
System administration password: admin
TCP/IP configuration: Obtain IP address settings automatically via DHCP
TCP/IP configuration: Disable Jumbo Frame
TCP/IP configuration: If port trunking is enabled (dual LAN models only), the port
trunking mode will be reset toActive Backup (Failover)”.
System Port: 8080 (system service port)
Security Level: Low (Allow all connections)
LCD panel password: (blank)*
VLAN will be disabled
*This feature is only provided by the NAS models with LCD panels. Please visit
http://www.qnap.comfor details.
Advanced system reset (10 sec)
Press the reset button for 10 seconds; you will hear two beeps at the third and the tenth
seconds. The NAS will reset all the system settings to default as it does by web-based
system reset in “Administration” > “Restore to Factory Default” except all the data are
reserved. The settings such as the users, user groups, and the network share folders
previously created will be cleared. To retrieve the old data after the advanced system reset,
create the same network share folders on the NAS and the data will be accessible again.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the QNAP TS-251+ and is the answer not in the manual?

QNAP TS-251+ Specifications

General IconGeneral
TypeNAS
BuzzerYes
Noise level15.4 dB
Device classHome & Home Office
Share folder512
Backup featuresCloud, USB drive, iSCSI LUN
Browser supportedApple Safari 7+, Google Chrome, Microsoft Internet Explorer 10+, Mozilla Firefox
Security algorithms256-bit AES, FIPS 140-2, HTTPS, SSH
Processor cores4
Processor model-
Processor familyIntel® Celeron®
Processor frequency2 GHz
Fan voltage12 V
AC input voltage100 - 240 V
Power supply locationExternal
Power consumption (sleep)0.57 W
Power consumption (typical)18.09 W
Power consumption (HDD standby)10.56 W
Power supply unit (PSU) capacity60 W
Flash memory512 MB
Memory slots2x SODIMM
Internal memory- GB
Memory clock speed1600 MHz
Internal memory typeDDR3L
Maximum RAM supported8 GB
Wi-FiNo
Ethernet LAN data rates10, 100, 1000 Mbit/s
Supported network protocolsCIFS/SMB, AFP v3.3, NFS v3, FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, SMSC
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 95 %
Chassis typeTower
Cooling typeActive
Fan diameter70 mm
Product colorBlack
LED indicatorsHDD, LAN, Power, Status, USB
Number of fans1 fan(s)
Cable lock slot typeKensington
Operating system version4.3
Operating system installedQNAP Turbo System
Mac operating systems supportedMac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supportedWindows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
RAID levels0, 1, JBOD
Storage drive size- \
Storage drive capacity4000 GB
Supported file systemsFAT32, HFS+, NTFS, exFAT, ext3, ext4
Installed storage drive typeHDD
Storage drive sizes supported2.5, 3.5 \
Supported storage drive typesHDD & SSD
Total installed storage capacity8 TB
Number of storage drives supported2
Supported storage drive interfacesSerial ATA II, Serial ATA III
Cables includedAC, LAN (RJ-45)
Number of screws14
Fiber ports quantity0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of simultaneous users4096 user(s)
Weight and Dimensions IconWeight and Dimensions
Depth219 mm
Width102 mm
Height169 mm
Weight1280 g
Package weight2320 g
