QNAP TS-253 Pro User Manual

111
Chapter 10. Use the LCD Panel
This feature is only available for NAS models with LCD panels.
LCD Panel – QTS 4.3.0 and above
You can use the LCD panel to configure system settings and view system information. You
can use the “ENTER” and “SELECT” buttons next to the panel to navigate through the LCD
menu.
After starting the NAS, you can see its name and firmware version appear on the panel.
N
A
S
5
F
4
D
E
3
4
.
3
.
0
(
2
0
1
6
0
7
0
3
)
After a few seconds, the panel will be automatically turned off. Then you can begin to
configure settings or view system information.
Viewing system IP address
1. Press “ENTER” or “SELECT” to turn on the panel.
2. Press “SELECT” to browse the NAS model name and the available IP addresses (for
each network and thunderbolt interface).
This feature is particularly useful when the NAS is near you.
Viewing and configuring system settings
When the name and firmware version of the NAS appear on the panel, press “ENTER” for
two seconds to view the Main Menu, which will automatically disappear if no further actions
are performed in ten seconds.
There are eight options on the Main Menu:
1. TCP/IP
2. Physical disk
3. Volume
4. System
5. Shut down
6. Reboot
7. Password
8. Back

QNAP TS-253 Pro Specifications

General

RAID levels	0, 1, JBOD
RAID support	Yes
Storage drive size	2.5/3.5 \
Storage drive capacity	- GB
Supported file systems	ext3, ext4, FAT32, HFS+, NTFS
Storage drive interface	Serial ATA II, Serial ATA III
Storage drives installed	No
Installed storage drive type	-
Supported storage drive types	HDD & SSD
Total installed storage capacity	0 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	0
Number of storage drives supported	2
Processor cores	4
Processor family	Intel® Celeron®
Processor frequency	2 GHz
Flash memory	512 MB
Internal memory	8 GB
Internal memory type	DDR3L
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, SMSC
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Chassis type	Tower
Cooling type	Active
Fan diameter	70 mm
Product color	Black
Number of fans	1 fan(s)
Cable lock slot type	Kensington
Type	NAS
Device class	Home & Home Office
Backup features	Cloud, iSCSI LUN
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SSH, SSL/TLS
Operating system version	4.1
Operating system installed	QNAP Turbo System
Fan voltage	12 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	0.74 W
Power consumption (typical)	16.34 W
Power supply unit (PSU) capacity	90 W
Cables included	LAN (RJ-45)
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	216 mm
Width	102 mm
Height	150 mm
Weight	1740 g
Package weight	2920 g
