Front Panel
No. Component No. Component
1 Status LED 7 M.2 SSD 1 LED
2 LAN LED 8 M.2 SSD 2 LED
3 USB LED 9 M.2 SSD 3 LED
4 Drive 1 LED 10 Power button
5 Drive 2 LED 11 USB One Touch Copy button
6 Drive 3 LED 12 USB One Touch Copy port
Rear Panel
TS-332X User Guide
Product Overview 7
