Component TS-453BT3
M.2 SSD type 2 x M.2 SSD SATA 6 Gbps
M.2 SSD form factor 2280
SSD cache acceleration support • Drive bays 1 to 4
• M.2 slots 1 to 2
• Optional: SSD using PCIe expansion slot
Hot-swappable Yes
Note
The following are not hot-swappable:
• M.2 SSDs
• SSD cache drives
• SSDs using PCIe expansion slots
Network
10 gigabit Ethernet ports 1 x 10GBASE-T RJ45
Gigabit Ethernet ports 2 x RJ45
External I/O Ports & Expansion Slots
PCIe slots 1 x PCIe 2.0 x2
Note
A QM2 expansion card is pre-installed on the PCIe
slot. The card includes a 10GBASE-T RJ45 port and
two M.2 SSD slots.
Thunderbolt ports 2 x Thunderbolt 3
USB ports 5 x USB 3.0
• Front: 1 x USB 3.0 One Touch Copy
• Back: 4 x USB 3.0
HDMI outputs 2 x HDMI 1.4b (up to 3840 x 2160 @ 30Hz resolution)
Audio • 2 x 3.5 mm dynamic microphone jacks
• 1 x 3.5 mm line-out jack
• 1 x speaker
Note
You cannot use the speakers and the line-out jack
simultaneously.
Interface
Display panel Monochrome OLED display with capacitive sensing Enter and Select
buttons
USB One Touch Copy Front: USB 3.0 Type-A
IR sensor QNAP RM-IR004 remote control (MCE compatible)
Dimensions
Form factor Tower
TS-453BT3 User Guide
Product Overview 5
