QNAP TS-453BT3 User Manual

END OF TERMS AND CONDITIONS
FCC Notice
FCC Class B Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired
operation.
Note
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/television technician for help.
Important
Any modifications made to this device that are not approved by QNAP Systems, Inc. may
void the authority granted to the user by the FCC to operate this equipment.
CE Notice
This QNAP NAS complies with CE Compliance Class B.
TS-453BT3 User Guide
Notices 63

QNAP TS-453BT3 Specifications

General

Stepping	B1
Tjunction	105 °C
Processor code	SR2Z9
Processor cache	2 MB
Processor cores	4
Processor model	J3455
System bus rate	- GT/s
Processor family	Intel® Celeron®
Processor socket	BGA 1296
Processor codename	Apollo Lake
Processor frequency	1.5 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	24 x 31 mm
CPU configuration (max)	1
Conflict-Free processor	Yes
PCI Express slots version	2.0
Processor boost frequency	2.3 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x2+2x1, 4x1
Thermal Design Power (TDP)	10 W
On-board graphics card model	Intel® HD Graphics 500
Maximum internal memory supported by processor	8 GB
Memory slots	2 x SO-DIMM
Internal memory type	DDR3L
RAID levels	0, 1, 5, 6, 10
Storage drive size	- \
Storage drive capacity	0 GB
Supported file systems	FAT32, HFS+, NTFS, ext3, ext4
Storage drive interface	-
Number of M.2 (M & B) slots	2
Storage drive sizes supported	2.5, 3.5 \
Supported storage drive types	HDD & SSD
Total installed storage capacity	0 TB
Number of storage drives installed	0
Supported storage drive interfaces	Serial ATA, Serial ATA II, Serial ATA III
Ethernet LAN data rates	1000, 10000 Mbit/s
Ethernet LAN data rate supported (max)	10000 Mbit/s
HDMI version	1.4b
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	5
Cables included	AC, LAN (RJ-45)
Number of screws	28
Chassis type	Tower
Cooling type	Active
Display type	OLED
Fan diameter	120 mm
Product color	Black
LED indicators	HDD, LAN, Status, USB
Number of fans	1 fan(s)
Cable lock slot type	Kensington
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply location	External
Power consumption (typical)	38.101 W
Power supply unit (PSU) capacity	120 W
Type	NAS
Device class	Home & Home Office
Share folder	CIFS/SMB, FTP, WebDAV
Backup features	Cloud, iSCSI LUN
Browser supported	Apple Safari 7, Google Chrome, Microsoft Internet Explorer 10, Mozilla Firefox
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SSH, SSL/TLS
Operating system version	5.0.0
Operating system installed	QNAP Turbo System
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Number of execution units	12
Maximum number of PCI Express lanes	6
Memory types supported by processor	DDR3L, LPDDR3-SDRAM, LPDDR4-SDRAM
Memory channels supported by processor	Dual
Intel Identity Protection Technology version	1.00
Intel Small Business Advantage (SBA) version	0.00
On-board graphics card base frequency	250 MHz
On-board graphics card burst frequency	750 MHz
Processor ARK ID	95594
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	226 mm
Width	170 mm
Height	168 mm
Weight	2510 g
Package weight	4050 g
