QNAP TS-53E Series Repair Manual

No. Component
(Quantity)
Screw Type
(Quantity)
Screwdriver
(Torque)
Attached To
7 LCD display module
(1)
Pan head
M2.5x3
(2)
Phillips #1
(3 kgf.cm / 2.60 lbf.in)
Chassis
8 Backplane
(1)
Pan head
M3x5
(12)
Phillips #2
(7 kgf.cm / 6.08 lbf.in)
Backplane tray
9 Backplane tray
(1)
Flat head
M3x4
(6)
Phillips #2
(5 kgf.cm / 4.34 lbf.in)
Chassis
10 Top bracket
(1)
Flat head
M3x4
(6)
Phillips #2
(7 kgf.cm / 6.08 lbf.in)
Chassis
11 System fan
(3)
Flat head
M5x10
(12)
Phillips #2
(5 kgf.cm / 4.34 lbf.in)
Rear panel
12 Rubber feet
(4)
Pan head
M5x10
(4)
Phillips #2
(5 kgf.cm / 4.34 lbf.in)
Chassis
13 Chassis
(1)
- - -
14 Power supply unit
bracket
(1)
Flat head
M3x4
(2)
Phillips #2
(7 kgf.cm / 6.08 lbf.in)
Chassis
15 Power supply unit
(1)
Flat head
#6-32x5
(4)
Phillips #2
(5 kgf.cm / 4.34 lbf.in)
Rear panel
16 Expansion card (PCIe
full height)
(1)
Pan head
M3x5
(1)
Phillips #2
(5 kgf.cm / 4.34 lbf.in)
Rear panel
| NAS Repair Manual
Category D NAS Models 138
