QNAP TS-53E Series Repair Manual

No. Component
(Quantity)
Screw Type
(Quantity)
Screwdriver
(Torque)
Attached To
4 Front panel
(1)
Flat head
M3x5
(2)
Phillips #2
(3 kgf.cm / 2.60 lbf.in)
Chassis
5 LCD display module
(1)
Flat head
M2.5x4
(4)
Phillips #1 Chassis
6 LED circuit board
(1)
Flat head
M3x5
(7)
Phillips #2 Chassis
7 Chassis
(1)
- - -
8 Expansion card (PCIe low
prole)
(1)
Flat head
M3x5
(1)
Phillips #2 PCIe bracket
9 PCIe cover
(1)
Flat head
M3x5
(1)
Phillips #2 Chassis
10 System board tray
(1)
Flat head
M3x4
(6)
Phillips #2 Chassis
11 • CPU fan
• System fan
(1)
Self-tapping
M3x10
(12)
Phillips #2 Rear panel
12 Rear panel
(1)
Flat head
M3x4
(9)
Phillips #2 Chassis
13 Drive tray key
(8)
- - -
14 Rubber feet
(4)
Flat head
M3X5
(4)
Phillips #2 Chassis
| NAS Repair Manual
Category C NAS Models 94
