QNAP TS-53E Series Repair Manual

No. Component
(Quantity)
Screw Type
(Quantity)
Screwdriver
(Torque)
Attached To
15 System board Flat head
M3X5
(9)
Phillips #2 System board
tray
16 Backplane - - Chassis
Optional Components
These components are not included with the original NAS but may be installed by the user.
Component
(Quantity)
Screw Type
(Quantity)
Screwdriver
(Torque)
Attached To
M.2 SSD
(2 maximum, not
included with original
NAS)
Pan head
M2.5x3
(2, included with
original NAS)
Phillips #2
(3 kgf.cm /
2.60 lbf.in)
Inserted into slot on riser
card, and then secured
to the drive cage with a
screw.
| NAS Repair Manual
Category C NAS Models 95
