5. Power on the NAS.
Installing M.2 Solid State Drives
Warning
• Only qualified personnel should perform the following steps. Failure to follow
instructions can result in serious injury or death.
• Observe electrostatic discharge (ESD) procedures to avoid damage to components.
Note
QNAP recommends installing heatsinks on the M.2 SSD controllers to enhance cooling
efficiency and to ensure consistent performance.
1. Power off the NAS.
2. Disconnect the power cord from the electrical outlet.
3. Disconnect all cables and external attachments.
4. Remove the case cover.
a. Remove the screws that secure the cover to the chassis.
b. Slide the cover back.
c. Pull the cover up until it completely detaches from the chassis.
TS-x77 User Guide
Installation and Configuration 21
