7. Remove the PCIe cover.
a. Remove the screw that secures the cover to the bracket.
b. Pull the cover away from the slot.
8. Install the expansion card.
a. Insert the card into the PCIe slot on the bracket.
b. Attach the screw.
TS-x77XU User Guide
Installation and Configuration 25
