Page #33 background imageLoading...
Page #33 background image
5. Connect the power cord to the PSU and the electrical outlet.
6. Power on the device.
Rail Kits
Rail kits are not included with the NAS and must be purchased separately. For details, contact an authorized
reseller or go to http://shop.qnap.com.
The TS-hx83XU-RP is compatible with the following rail kit models:
Model Compatible Rail Kit
TS-h1683XU-RP RAIL-A03-57
TS-h2483XU-RP RAIL-A02-90
You can nd installation information in the rail kit package.
Expansion Unit Installation
The TS-hx83XU-RP supports SAS expansion units. For details, please see table below.
The device supports SAS expansion units, SATA JBOD expansion units, and USB expansion units. For details,
please see table below.
You can purchase storage expansion accessories from QNAP or an authorized reseller.
For details, go to https://shop.qnap.com/.
For the list of compatible expansion units and the maximum number of applicable expansion units, go to
http://www.qnap.com/go/compatibility-expansion.
Expansion Unit Model Description Required Accessories
REXP-1620U-RP Uses a SAS 12 Gbps (SFF-8644)
interface
Supports SAS/SATA HDD/SSD
SAS-12G2E storage expansion
card
mini-SAS SFF-8644 cable
RAIL-A03-57
REXP-1220U-RP
REXP-1610U-RP Uses a SAS 6 Gbps (SFF-8644)
interface
Supports SATA/HDD/SSD
SAS-12G2E storage expansion
card
mini-SAS SFF-8644 cable
RAIL-A03-57
REXP-1210U-RP
TL-D400S Uses a SAS 6 Gbps (SFF-8088)
interface
Supports SATA/HDD/SSD
1 x SFF-8088 connector cable
QXP-400eS-A1164 host bus
adapter
TL-D800S Uses a SAS 6 Gbps (SFF-8088)
interface
Supports SATA/HDD/SSD
2 x SFF-8088 connector cables
QXP-800eS-A1164 host bus
adapter
TS-hx83XU-RP User Guide
Installation and Conguration 32
