Component TS-h1683XU-RP-E2236-128G TS-h2483XU-RP-E2236-128G
Dimensions (H x W
x D)
130 x 481 x 573.5 mm
5.12 x 18.93 x 22.58 in
176.15 x 481.04 x 672.02 mm
6.94 x 18.94 x 26.46 in
Net weight 13.76 kg
(30.34 lbs)
20.67 kg
(45.57 lbs)
Others
Rail compatibility RAIL-A03-57 RAIL-A02-90
Note
• Rail kits are not included with the NAS and must be purchased
separately. For details, contact an authorized reseller or go to
http://shop.qnap.com.
• Information on rail kit installation can be found in the
installation guide included in the rail kit package.
Power supply unit TS-h1683XU-RP: 2 x 500W, 100-240V AC,
50/60 Hz
TS-h2483XU-RP: 2 x 800W, 100-240V AC,
50/60 Hz
System battery CR2032 lithium battery (3V, 225 mAh)
Sound level 53 dB(A) 28.7 dB(A)
Note
The sound level was tested at a bystander position, which is within
one meter of the NAS. The test NAS operated at low speed with
the maximum number of drives installed.
Fans • TS-h1683XU-RP: 4 x 92mm, 12V DC system fans
• TS-h2483XU-RP : 3 x 80mm, 12V DC system fans
Operating
temperature
0˚C to 40˚C (32˚F to 104˚F)
Relative humidity • Non-condensing relative humidity: 5% to 95%
• Wet-bulb temperature: 27˚C (80.6˚F)
Tip
For the list of compatible drive models and expansion cards, go to https://www.qnap.com/
compatibility.
Package Contents
Item Quantity
TS-hx83XU-RP NAS 1
Power cord • TS-h1683XU-RP: 2
• TS-h2483XU-RP: 2
Ethernet cable • 2 x 1GbE (Cat5e)
• 2 x 10GbE (Cat6a)
Screws for 2.5-inch drives • TS-h1683XU-RP: 64
• TS-h2483XU-RP: 96
TS-hx83XU-RP User Guide
Product Overview 6
