QNAP TS-h1683XU-RP User Manual

Component TS-h1683XU-RP-E2236-128G TS-h2483XU-RP-E2236-128G
Memory slots 4 x Long-DIMM DDR4
Important
Use only QNAP memory modules to maintain system performance
and stability. For NAS devices with more than one memory slot,
use QNAP modules with identical specications.
Using unsupported modules may degrade performance, cause
errors, or prevent the operating system from starting.
Maximum memory 128 GB RAM: 4 x 32 GB
Flash memory 5 GB (dual-boot OS protection)
Storage
Drive bays 16 x 3.5-inch SATA 6 Gbps 24 x 3.5-inch SATA 6 Gbps
Note
The SATA 6 Gbps interface is backward compatible with SATA 3
Gbps.
Drive compatibility 3.5-inch bays:
• 3.5-inch SATA hard disk drives
• 2.5-inch SATA hard disk drives
• 2.5-inch SATA solid-state drives
SSD cache
acceleration
support
3.5-inch drive bays: 1 to 16 3.5-inch drive bays: 1 to 24
Hot-swapping Supported
Network
10 Gigabit network
interface
• 2 x 10 GbE SmartNIC SFP+
• 2 x 10GBase-T RJ45
Gigabit network
interface
4 x GbE RJ45
Wake-on-LAN Yes (GbE RJ45)
External I/O Ports & Expansion Slots
PCIe slots • 1 x PCIe Gen 2 x 4
• 2 x PCIe Gen 3 x 4
• 1 x PCIe Gen 3 x 8
• 3 x PCIe Gen 2 x 4
• 1 x PCIe Gen 3 x 4
• 1 x PCIe Gen 3 x 8
USB ports • 4 x USB 3.2 Gen 2 (10 Gbps) Type-A
• 2 x USB 3.2 Gen 2 (10 Gbps) Type-C
Interface
Buttons • Power
• Reset
Dimensions
Form factor 3U Rackmount 4U Rackmount
TS-hx83XU-RP User Guide
Product Overview 5
