Component TVS-472XT TVS-672XT TVS-872XT
Audio ports • 1 x 3.5 mm dynamic microphone jack
• 1 x 3.5 mm line-out jack
• 1 x speaker
Note
You cannot use speakers and line-out jacks simultaneously.
Interface
Display panel Monochrome backlit LCD display
Buttons • Power
• Reset
• USB One Touch Copy
IR sensor 1
Note
The TVS-x72XT supports the QNAP RM-IR004 IR remote
control.
Dimensions
Form factor Tower
Dimensions (H x W x D) 188.2 x 199.3 x 279.6
mm
(7.41 x 7.85 x 11.01 in)
188.2 x 264.3 x 279.6
mm
(7.41 x 10.40 x 11.01 in)
188.2 x 329.3 x 279.6
mm
(7.41 x 12.96 x 11.01 in)
Net weight 5.4 kg (11.9 lbs) 6.5 kg (14.3 lbs) 7.0 kg (15.5 lbs)
Others
Power supply unit 1 x 250W, 100-240V AC, 50/60 Hz
System battery CR2032 lithium battery (3V, 225 mAh)
Warning
To avoid potential battery explosion, causing injury or damage
to components, ensure that you replace the existing battery
with a battery of the same type.
Sound level 28.1 db(A) 23.8 db(A) 24.2 db(A)
Note
The sound level was tested at a bystander position, which is
within one meter of the NAS. The test NAS operated at low
speed with the maximum number of drives installed.
TVS-x72XT User Guide
Product Overview 6
