22
TCP/IP
UBasic
In this page, you can change the TCP/IP settings of this Access Point, select to
enable/disable the DHCP Client, 802.1d Spanning Tree, and Clone MAC Address.
IP Address
This field can be modified only when DHCP Client is
disabled. If your system manager assigned you static IP
settings, then you will have to enter the information provided.
Subnet Mask
Enter the information provided by your system manager.
Default Gateway
Enter the information provided by your system manager.
DHCP
Select Disable, Client or Server from the pull-down menu.
Disable: Select to disable DHCP server function.
Client: Select to automatically get the LAN port IP address
from ISP (For ADSL/Cable Modem).
Server: Select to enable DHCP server function.
DHCP Client Range
253 IP addresses continuing from 192.168.1.1 to
192.168.1.253
Show Client
Click to show Active DHCP Client table.
DNS Server
Enter the Domain Name Service IP address.
To Next Page
