QRPproject Speaky - Page 52

Version: 13. Sepe,mer 2004
52
RFSim99 - D:\Eigene Dateien\_PM_Manuals\SPEAKY\TPF80m.cct
10dB
S21
10Log(P)
-50dB
10dB
S11
10Log(P)
-50dB
Marker: f=4.169MHz Trace1:-0.2dB Trace2:-14.2dB
Start:1MHz
Stop:100MHz101 points
RFSim99 - D:\Eigene Dateien\_PM_Manuals\SPEAKY\TPF30m.cct
10dB
S21
10Log(P)
-50dB
10dB
S11
10Log(P)
-50dB
Marker: f=10.965MHz Trace1:-0.2dB Trace2:-13.7dB
Start:1MHz
Stop:100MHz101 points
RFSim99 - D:\Eigene Dateien\_PM_Manuals\SPEAKY\TPF17m.cct
10dB
S21
10Log(P)
-50dB
10dB
S11
10Log(P)
-50dB
Marker: f=19.055MHz Trace1:-0dB Trace2:-25.9dB
Start:1MHz
Stop:100MHz101 points
RFSim99 - D:\Eigene Dateien\_PM_Manuals\SPEAKY\SpeakyBilder\TPFMainboard.cct
10dB
S21
10Log(P)
-50dB
10dB
S11
10Log(P)
-50dB
Marker: f=31.623MHz Trace1:-0dB Trace2:-23.7dB
Start:1MHz
Stop:100MHz101 points
