Current Draw Table (in Amperes)
Table 3 provides typical current draw for each model as a function of load and output power level. Units of measurement are Amperes r.m.s.
NOTE:
Current draw shown is for 120 VAC line. For 230 VAC models, multiply values shown by 0.5 .
• 1/8 power (pink noise) represents typical program with occasional clipping. Use this rating for most applications.
• 1/3 power (pink noise) represents severe program with heavy clipping.
• Full power (sine) is continuous sine wave driven at 1% clipping.
• Thermal or overcurrent cutback limits duration of full power 2 Ohm operation.
Model Load Idle
1/8 Power
(pink noise)
1/3 Power
(pink noise)
Full Power
(sine)
CX204V 70V (x4) 0.8 7.7 12.1 14.0
CX254 8 (x2)
4 (x2)
2 (x2)
0.7
0.7
0.7
5.8
9.2
14.3
8.8
14.2
24.0
14.8
24.0
38.0
CX302 8 (x2)
4 (x2)
2 (x2)
0.8
0.8
0.8
3.8
6.0
9.6
5.4
8.9
14.3
8.4
14.0
23.0
CX302V 70V (x2) 0.8 5.7 8.0 16.0
CX404 8 (x2)
4 (x2)
0.7
0.7
8.1
12.4
12.2
19.3
22.0
38.0
CX502 8 (x2)
4 (x2)
2 (x2)
0.9
0.9
0.9
5.6
9.0
14.0
8.0
13.3
21.0
12.5
21.0
34.0
CX602V 70V (x2) 0.9 8.7 13.0 21.0
CX702 8 (x2)
4 (x2)
2 (x2)
0.9
0.9
0.9
5.0
7. 9
11.8
8.4
13.5
22.0
15.8
26.0
42.0
CX902 8 (x2)
4 (x2)
2 (x2)
0.9
0.9
0.9
6.0
9.5
14.0
11.0
17.0
27.0
20.0
33.0
50.0
CX1102 8 (x2)
4 (x2)
2 (x2)
0.9
0.9
0.9
7. 6
11.6
16.6
13.1
20.0
25.0
39.0
CX1202V 70V (x2) 0.9 12.0 19.0 39.0
— Table 3 —
