QSC CX902

15
EN
TD-000077-00-K
2-Channel Low-Impedance Models
CX302 CX502 CX702 CX902 CX1102
Output Power (Watts)
20 - 20k Hz, 0.03% THD, 8 Ohms/Ch. 200 300 425 550 700
20 - 20k Hz, 0.05% THD, 4 Ohms/Ch. 325 500 700 900 1100
1k Hz, 1.0% THD (EIA), 8 Ohms/Ch. 215 325 475 625
1k Hz, 1.0% THD (EIA), 4 Ohms/Ch. 375 550 825 1050
1k Hz, 1.0% THD (EIA), 2 Ohms/Ch. 600 800 1200 1500 1700
Bridge Mono, 20 - 20k Hz, 0.1% THD, 16 Ohms 400 600 850 1100 1400
Bridge Mono, 20 - 20k Hz, 0.1% THD, 8 Ohms 700 1000 1500 2000
Bridge Mono, 1k Hz, 1.0% THD, 8 Ohms
Bridge Mono, 1k Hz, 1.0% THD, 4 Ohms 1200 1600 2400 3000 3400
Distortion, SMPTE-IM <0.01% <0.01% <0.02% <0.02% <0.02%
Frequency Response 20 - 20k Hz, ±0.2dB at 10dB below rated output power, all models (-3dB points: 8 Hz and 100 kHz)
Signal To Noise, Unweighted, 20 - 20K Hz -106 dB -107 dB -106 dB -104 dB -106 dB
Voltage Gain 31.5x (30dB) 40.0x (32dB) 50.5x (34dB) 56.6x (35dB) 56.6x (35dB)
Input Sensitivity, Vrms
For Rated Power Into 8 Ohms
For Rated Power Into 4 Ohms
1.26 (+4.2dBu)
1.14 (+3.4dBu)
1.23 (+4.0dBu)
1.12 (+3.2dBu)
1.16 (+3.5dBu)
1.05 (+2.6dBu)
1.17 (+3.6dBu)
1.06 (+2.7dBu)
1.35 (+4.8dBu)
1.17 (+3.6dBu)
Output Circuit Type AB AB H H H
Input Impedance 6k ohms unbalanced, 12k ohms balanced, all models
Dynamic Headroom 2 dB at 4 Ohms, all models
Damping Factor >500 at 8 Ohms, all models
Amplifier Protection Short circuit, open circuit, thermal, ultrasonic and RF protection. Stable into reactive or mismatched loads
Cooling Continuously variable speed fan; back-to-front air flow through heat sink tunnel
Controls
Front
Back
AC POWER switch, gain controls (1 control per channel, 21 detents)
10-position DIP switch with Clip Limiter (1 per Ch.), LF Filter on/off (1 per Ch.) LF filter select: 33 or 50 Hz (1 per Ch.), Stereo/
Parallel/Bridge mode selection switches
Led Indicators POWER (green, 1 each), SIGNAL, -10dB, -20dB (green, 1 each per Ch.), CLIP (red, 1 each per channel), BRDG and PAR
(yellow, 1 each)
Connectors
Input
Output
Other
3-pin terminal blocks ("euro" or "Phoenix" type) and XLRs (pin 2 positive)
barrier strip connectors with protective shroud
QSC DataPort connector (supports full “V1”feature set)
Load Protection Turn-on/turnoff muting, AC coupling (DC fault blocking), Clip limiting.
Power Requirements Refer to rear panel serial number label. Configured at factory for 100, 120 or 220-240 VAC, 50- 60 Hz.
Dimensions 19.0" (48.3 cm) W, 3.5" (8.9 cm) H, 14" (35.6 cm) D (from front mounting rails, including rear support ears)
Weight 21 pounds (9.5 kg) net; 27 pounds (12.3 kg) shipping
