Quadra-Fire CB1200 - Installation into a Masonry Fireplace; Prefabricated Metal Chimney

August 1, 2018 7014-285C 13
CB1200 Pellet Insert
NOTICE: In Canada when using a factory-built chimney
it must be safety listed, Type UL103 HT
(2100
o
F) [1149
o
C] CLASS “A” or conforming
to CAN/ULC-S629M, STANDARD FOR 650
o
C
FACTORY-BUILT CHIMNEYS.
H. Prefabricated Metal Chimney
The chimney can be new or existing, masonry or prefabricated
and must meet the following minimum requirements:
• Must be minimum 6 inch (152mm) inside diameter of
high temperature chimney listed to UL 103 HT (2100
o
F)
or ULC-S628.
• Must use components required by the manufacturer for
installation.
• Must maintain clearances required by the manufacturer
for installation.
• Refer to manufacturers instructions for installation
• This insert is listed to ASTM E 1509-12 Standard and
is approved for installation into listed factory-built zero
clearance replaces listed to UL 127 conforming to the
following specications and instructions:
• The original factory-built clearance replace chimney
cap must be re-installed after installing the approved
chimney liner meeting type UL 103 HT requirements
(2100°F) per UL 1777.
• If the chimney is not listed as meeting HT
requirements, or if the factory built replace was tested
prior to 1998, a full height listed chimney liner must be
installed from the appliance ue collar to the chimney
top.
• The liner must be securely attached to the insert ue
collar and the chimney top.
• The air ow of the factory-built zero-clearance replace
system must not be altered. The ue liner top support
attachment must not reduce the air ow for the existing
air-cooled chimney system.
• No dilution air is allowed to enter the chimney.
Risk of Fire!
Follow venting manufacturer’s clearances and
instructions when installing venting system.
WARNING
NOTE
It is necessary to permanently seal any opening between
the masonry of the replace and the facing masonry.
1. Secure the replace damper in the open position. If
this cannot be accomplished, it will be necessary to
remove the damper
2. Seal damper area of chimney around chimney
connector with a high temperature sealant or seal insert
against the face of the replace.
3. Both methods must be removable and replaceable for
cleaning and re-installation.
• Removing oor of replace must not weaken
structure of rebox or reduce protection for
combustible materials.
• Final approval of this installation type is contingent
upon the appropriate local authority having
jurisdiction.
WARNING
G. Installation into a Masonry Fireplace
All modications that can be made to a Factory Built Fire-
place can be made to a Masonry Fireplace.
In addition DO NOT remove any brick or mortar from the
existing replace.
