2 7014-285C August 1, 2018
CB1200 Pellet Insert
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.
Quadra-Fire is a registered trademark of Hearth & Home Technologies.
1 Important Safety Information .............3
A. Appliance Certication....................... 3
B. BTU & E󰀩ciency Specications ............... 3
C. Glass Specications ........................ 4
D. Electrical Rating ........................... 4
E. Mobile Home Approved ..................... 4
F. Non-Combustible Materials................... 4
G. Combustible Materials ...................... 4
H. Sleeping Room ............................ 4
I. California - Prop65 .......................... 4
2 Getting Started ....................................5
A . Design, Installation & Location Considerations .........5
B. Thermostat Wall Control Location .............. 6
C. Tools And Supplies Needed .................. 6
D. Inspect Appliance and Components ............ 6
E. Install Checklist ............................ 7
3 Dimensions and Clearances ..............8
A. Appliance Dimensions ....................... 8
B. Clearance To Combustibles, UL and ULC........ 9
C. Minimum Opening for Masonry ............... 10
....& Zero Clearance Fireplaces ............... 10
D. Hearth Extension.......................... 10
E. Floor Protection .......................... 11
F. Installation into a Factory-Built Fireplace ........ 12
G. Installation into a Masonry Fireplace .......... 13
H. Prefabricated Metal Chimney ................ 13
4 Vent Information ................................14
A. Venting Termination Minimum Requirements .... 14
B. Avoiding Smoke and Odors.................. 15
C. Negative Pressure......................... 16
D. Draft ................................... 16
E. Chimney and Exhaust Connection ............ 16
F. E quivalent Feet of Pipe ..................... 17
G. Pipe Selection Chart ...................... 17
5 Venting Systems ...............................18
A. Full Reline With Outside Air - Horizontal ........ 18
B. Full Reline With Outside Air - Vertical.......... 19
6 Appliance Set-Up ..............................20
A. Rear Shroud Installation.................... 20
B. Outside Air Kit Instructions .................. 22
C. Adjustable Hopper Options .................. 23
D. Grill Installation ........................... 23
E. Adjustable Hearth Support .................. 23
F. Panel and Trim Set ........................ 24
G. Thermostat Installation and Operation......... 26
H. Optional Log Set Placement Instructions ....... 28
7 Mobile Home Installation ..................29
8 Reference Materials ..........................30
A. Service & Maintenance List.................. 30
B. Accessory List ............................ 32
