GARNET DIRECT VENT ROOM HEATER
250-6443B October 7, 2003 Page 13
GARNET DIRECT VENT ROOM HEATER
250-6443B October 7, 2003 Page 14
SIMPSON DURA-VENT and HTI PARTS LIST
Termination Caps & Snorkels:
991 High Wind Vertical Termination Cap
985 High Wind Horizontal Termination Cap
983 Vertical Termination
981 Snorkel Termination (36”)
982 Snorkel Termination (14”)
950 Vinyl Siding Standoff (VSS)
Flashing:
941 Cathedral Ceiling Support Box
943 Flashing, 0/12 to 6/12 Roof Pitch
943S Flashing, 7/12 to 12/12 Roof Pitch
943F Flashing, Flat Roof
Support Boxes/Thimbles:
940 Round Ceiling Support/Wall Thimble Cover
941 Cathedral Ceiling Support Box
942 Wall Thimble
Pipe:
908 6” Pipe Length, Galv.
908B 6” Pipe Length, Black
907 9” Pipe Length, Galv
907B 9” Pipe Length, Black
906 12” Pipe Length, Galv.
906B 12” Pipe Length, Black
904 24” Pipe Length, Galv.
904B 24” Pipe Length, Black
903 36” Pipe Length, Galv.
903B 36” Pipe Length, Black
902 48” Pipe Length, Galv.
902B 48” Pipe Length, Black
911 11” -14 5/8” Pipe, Adj. Galv.
911B 11” -14 5/8” Pipe, Adj. Black.
912 12” - 17” Pipe, Adj. Galv.
912B 12” - 17” Pipe, Adj. Black.
917 17” -24” Pipe, Adj. Galv.
917B 17” -24” Pipe, Adj. Black.
945 45° Elbow, Galv.
945B 45° Elbow, Black
990 90° Elbow, Galv.
990B 90° Elbow, Black
Decorative Trim Kits
3951 Round Celing Support; Wall Thimble Trim Kit,
Polished Brass
3960
Cathedral Ceiling Support Trim Kit, Polished Brass
SDV KITS
970A Standard Termination Kit includes 1 each of:
990B, 940, & 985. See Note below.
971HW Standard Termination Kit includes 1 each of:
990B, 940, 985, 904B, 911B
973 Vertical Termination Kit includes 1 each of:
943, 953, 991 (support box NOT included)
HTI'S VENT PARTS LIST
HHW2 841-0670 Horizontal High Wind Cap
(recommended for optimal perfor-
mance)
HHW2K 844-4490 Horizontal Kit (One 90°
Black
Elbow, Wall Thimble, 24” Black Pipe,
11”-14-5/8” Adjustable Vent, HHW2
Termination Cap)
RHVK 844-8920 Snorkel Kit #844-8920 (with Dura-
Vent part #'s 911B and 940)
Misc.
953 Storm Collar
963 Ceiling Firestop
988 Wall Strap
9546 Attic Insulation Shield
923GK Chimney Liner Termination Kit
923GCL
Co-axial / Co-lineal Appliance Connector
909B Retrot Adj. Chimney Connector Retrot
Chimney Connector Plate
NOTE: Straight pipe lengths are needed to complete
installation; the black 45
° elbow is NOT included in kit.
SECURITY CHIMNEY'S SECURE VENT CHIMNEY SYSTEM
& AMERIVENT DIRECT VENTING COMPONENTS
Your Quadra-Fire Garnet has been approved with Security Chimney's Secure Vent Chimney System and Amerivent Direct
Venting Components. All the required certification tests have been successfully completed with OMNI-Test Laboratories,
Inc. Please contact your local dealer and they will advise you of the required parts needed for your installation. It is required
to use High Temperature RTV Sealant at the inner and outer joint connection of the first section to the supplied listed direct
vent starter section.
