Quadra-Fire Garnet - Parts & Accessories & Explosed View Schematic

GARNET DIRECT VENT ROOM HEATER
250-6443B October 7, 2003 Page 41
R
GARNET DIRECT VENT ROOM HEATER
250-6443B October 7, 2003 Page 42
R
PARTS & ACCESSORIES
Part Number DESCRIPTION
844-9370 Blower Assembly with Speed Control (Thermostat capability)
812-3760 Manual Thermostat
811-0520 Programmable Thermostat
841-0960 Remote Control, Smart Stat
841-0970 Remote Control, Smart Batt
842-4980 Log Set, 3 piece, complete
842-0370 Speed Control (Rheostat)
812-1560 Snap Disc for Blower
812-3821 Magnet Latch
220-0640 Door Latch
842-0320 On/Off (Rocker) Switch
844-9550 Slim-Line Wall Thimble
844-9580 Burner Kit
GLA-TP Glass Assembly with Frame
EXPLODED VIEW SCHEMATIC
1 Cast Sides - Left or Right
2 Blower (Fan) Motor
3 Blower Housing
4 (2) Log Pan Supports
5 Pilot Bracket
6 Pilot Assembly
7 Burner
8 (2) Burner Supports
9 Glass Frame
10 Face
11 Glass
12 Log Pan
Number Description
13 Bafe
14 Pressure Relief Assembly
15 Ignition Module
16 Valve Bracket
17 Valve
18 Valve Cover & Access Door
19 Cast Stove Top
20 Back Shield
21 (2) Door Latches
22 Ignition Module Bracket
23 On/Off Switch
Number Description
PLEASE CONTACT YOUR DEALER TO ORDER REPLACEMENT PARTS
